The LabCollector system architecture is shown in the diagram below.
IT Requirements and other information:
|
CPU and Memory (Windows Server):
|
- Operating system: Windows 10 or Windows Server 2012 or later
- CPU : Min. (2 Cores) , Recommended (4 Cores)
- Memory : Min. (4GB) , Recommended (8GB)
|
|
System requirements:
|
- Windows 7/10 and WinServer 2012 and up, Linux, Unix and MacOS X 10.x. and many others.
- Apache, Nginx, IIS Web Server. IIS is a standard option of Windows. Apache runs on Windows too.
- PHP 7.4 to 8.1 for LabCollector V6.3+; PHP 5.6 to 7.4 for legacy versions (http://www.php.net)
- MySQL database server 5.x or MariaDB or PerconaSQL (http://www.mysql.com)
- A modern web browser with Ajax support
|
|
Login Validations:
|
- Supports LDAP & Active Directory (SSO)
Please click the  KB: Knowledge Base link to see more about these options.
|
|
User level permissions in LC:
|
- Super-Admin; Admin; Staff; Staff+; Visitor
A full description of each role is available in the  KB: Knowledge Base.
|
|
Data Backup:
|
- Automated data backups can be configured using the LabCollector Server Manager
|
LabCollector is accessed through a web browser. After logging in, the interface will appear as shown in section 1.2.
